PLC Automatic Liquid Filling Machine 1000ml Automatic Water Bottle Filling Machine

PLC Automatic Liquid Filling Machine 1000ml Automatic Water Bottle Filling Machine

  • PLC Automatic Liquid Filling Machine 1000ml Automatic Water Bottle Filling Machine
  • PLC Automatic Liquid Filling Machine 1000ml Automatic Water Bottle Filling Machine
PLC Automatic Liquid Filling Machine 1000ml Automatic Water Bottle Filling Machine
Product Details:
Place of Origin: Jiangsu,China
Brand Name: XIANFEI
Certification: ISO
Model Number: LD-8L
Payment & Shipping Terms:
Minimum Order Quantity: 1Set
Price: 17600-20000USD
Packaging Details: Wooden case
Delivery Time: 30 days after receiving your sample bottles and caps
Payment Terms: T/T
Supply Ability: 15 sets per month
Contact Now
Detailed Product Description
Model: LD-8L Straight Line Automatic Liquid Peristaltic Pump Filling Machine Control: PLC Touch Screen Control
Air Pressure: 0. 5-0. 7Mpa Power Source: 380V, 50Hz
Total Power: 3. 0KW Weight: 650Kg
High Light:

PLC Touch automatic liquid filling machine

,

1000ml automatic liquid filling machine

,

1000ml automatic water bottle filling machine



PLC Touch Screen Control 650 Kilogram Peristaltic Pump Filling Machine





Specifications:



Model of machine LD-8L
Control PLC touch screen control
Air pressure 0. 5-0. 7Mpa
Power source 380V, 50Hz
Total power 3. 0KW
Weight 650Kg





Introduction:



1. The pump source of the peristaltic pump is a peristaltic pump, which makes full use of the characteristics of the peristaltic pump and has simple structure.



2. The pump body has no place to contact the filling liquid, so it is unnecessary to clean and disinfect the pump body.



3. The pump is driven by servo motor, PLC control to adjust the load is simple, only input the corresponding number can be realized, can be adjusted at any time in the working state, precision up to ±1%.





Applications:



1. Excellent performance when filling daily chemical products such as laundry detergent and detergent.



2. Microemulsions and suspending agents needed in pesticides can also be used for filling.



3. It can be filled with most types of liquids, including liquids of high viscosity. Such as: all kinds of pharmaceutical, chemical, oil, cosmetics, food and other non-granular liquid.



4. This machine has the advantages of simple and novel structure, convenient maintenance and adjustment, stable operation, low noise and high degree of automation. It has inverted bottle stop control, non-bottle stop filling control, alarm and automatic speed reduction for lack of plug or cap. When the plug or cap is supplied, the speed will automatically rise to the set range.





Elements brands list:



Name Brand and materials
Servo motor Panasonic
Ballscrew WIHIN
PLC Mitsubishi
Touch screen Weinview
Air cylinder AirTAC
Three-way valve XIANFEI
Electromagnetic valve SHAKO
Optoelectronic switch Sick







PLC Touch Screen Control 650 Kilogram Peristaltic Pump Filling Machine



Competitive Advantage:



1. The machine is mainly made of high quality stainless steel.



2. Adopt special three-way filling valve.



3. PLC programmable control is adopted.



4. 6-inch touch screen man-machine interface system.



5. Fully automated.Automatic bottling, automatic filling.



6. Pneumatic components adopt well-known brands, such as Mitsubishi, Panasonic, etc.





FAQ:



Q: How many years of experience do you have in packaging machinery and equipment?

A: We have 16 years of experience in manufacturing packaging machinery and equipment.



Q: Do you guarantee the quality of your products?

A: Sure.We take our reputation very seriously.Quality first is our consistent principle.The company passed the Jiangsu high-tech enterprise certification in 2020.You can rest assured of the quality of our products.



Q: Where is your factory located?

A: Our factory is located in Jintan Economic Development Zone, Changzhou City, Jiangsu Province, China. It takes 2 hours by high-speed train to Shanghai



Q: How to install it?

A: We can provide installation.There are two options.The first option: we can send our engineers to your company for debugging and maintenance, and your company will bear the cost of air ticket, visa, accommodation, labor and other expenses for this trip.Option 2: Offer an online service.



Q: How to ensure the operation of the filling machine?

A: Before delivery, we will test and debug all the machines in good condition and record the video for your inspection.
