Mechanical 1.2KW Wine Bottle Screw Capping Machine 140mm Pet Bottle Capping Machine

Mechanical 1.2KW Wine Bottle Screw Capping Machine 140mm Pet Bottle Capping Machine

  • Mechanical 1.2KW Wine Bottle Screw Capping Machine 140mm Pet Bottle Capping Machine
  • Mechanical 1.2KW Wine Bottle Screw Capping Machine 140mm Pet Bottle Capping Machine
Mechanical 1.2KW Wine Bottle Screw Capping Machine 140mm Pet Bottle Capping Machine
Product Details:
Place of Origin: Jiangsu,China
Brand Name: XIANFEI
Certification: ISO
Model Number: FXZ-4L
Payment & Shipping Terms:
Minimum Order Quantity: 1Set
Price: 5280-6000USD
Packaging Details: Wooden case
Delivery Time: 30 days after receiving your sample bottles and caps
Payment Terms: T/T
Supply Ability: 15 sets per month
Contact Now
Detailed Product Description
Model: FXZ-4L Material: SUS304
Bottle Diameter: 45-140mm Diameter Of Cap: 20~50mm
Design: Mechanical-electrical Integration Applicability: Wide Range
Bottle Shape: All Kinds Of Bottles Total Power: 1.2kw
High Light:

1.2KW wine bottle screw capping machine

,

140mm wine bottle screw capping machine

,

140mm pet bottle capping machine



Mechanical 1.2KW Wine Bottle Screw Capping Machine 140mm Pet Bottle Capping Machine





Features:



1. PLC touch type operation interface, simple setting, convenient operation, practical and beautiful.



2. The capping speed is fast. Compared with the claw capping machine, the capping speed of this machine can be improved by 3-4 times, and effectively

To prevent the bottle body hair, bottle cap damage and other problems.



3. It is suitable for all kinds of bottles in the applicable range. Just adjust the spacing of the synchronous belt, the capping wheel and the height of the rack, no need to replace the machine parts.



4. It is suitable for all kinds of bottles whose body shape is round, square, flat and round.



5. It can be used as a single machine, or can be matched with filling, sealing, labeling and other equipment to form an automatic mechanical filling production line.





Machine Parameter:



Model FXZ-4L
Material SUS304
Bottle Diameter 45-140mm
Diameter of cap 20~50mm
Design mechanical-electrical integration
Applicability Wide range
Bottle shape All kinds of bottles
Total Power 1.2kw





Machine advantages:



1. Straight line design, convenient and beautiful assembly line.



2. The speed of the host adopts imported frequency converter, which can carry out stepless speed regulation and automatic counting.



3. The use of strong electromagnetic left-turn cap torsion, completely solve the traditional mechanical friction plate in the tight and loose in the cap.







Machine configuration
1 Main motor Taiwan
2 Solenoid valve SHAKO
3 Cylinder Air TAC
4 Photoelectric OMRON
5 Inverter Panasonic







Mechanical 1.2KW Wine Bottle Screw Capping Machine 140mm Pet Bottle Capping Machine





XIANFEI service:



Machine Customization Service



1. We can customize the machine according to your requirements. Such as the need for special materials, voltage size, the shape of the bottle and so on.

2. We have professional mechanical engineers who can give you some professional advice. As you know, our company has been engaged in the research, development and manufacture of filling machines for 16 years.

3. According to your requirements, we can reasonably plan the whole filling line for you, and provide some suggestions about the machine according to your needs.



Reliable after-sales service



1. We will deliver the goods within the promised delivery period and provide you with the B/L to ensure that you can get the machine quickly. Send operation manuals and instructions at the same time.

2. If you need, our team of professional engineers will come to your factory to install the machines and train your employees until they can operate the machines well.

The machine has a one year free warranty.

3. 24-hour engineer response.



Mechanical 1.2KW Wine Bottle Screw Capping Machine 140mm Pet Bottle Capping Machine 0



What services can Changzhou Xianfei Packing Equipment Technology Co., Ltd. provide for you?



1. Product inspection

We have our own factory and quality control department, and we will check carefully to ensure the quality of the products before sending them to our customers



2. Sample services

We can send you a video of the machine in action.Welcome to visit our company and have a look at the machines being produced in our factory



3. Customization services

A: We can customize the machine according to the mechanical power, materials and bottles you provide

B: We can also offer you some professional advice on machinery.As you know, we have been in the machinery business for 16 years.



4. About install

We can provide installation.There are two options.

The first option: We can send our engineers to your company for debugging and maintenance, and your company will bear the cost of air ticket, visa, accommodation, labor and other expenses for this trip.

Option 2: Offer an online service.
