Inline Vacuum Bottle Filler 50ml Plastic Bottle Filling Machine

Inline Vacuum Bottle Filler 50ml Plastic Bottle Filling Machine

Inline Vacuum Bottle Filler 50ml Plastic Bottle Filling Machine
Inline Vacuum Bottle Filler 50ml Plastic Bottle Filling Machine
Inline Vacuum Bottle Filler 50ml Plastic Bottle Filling Machine
Product Details:
Place of Origin: Jiangsu,China
Brand Name: XIANFEI
Certification: ISO
Model Number: ZCG-12L
Payment & Shipping Terms:
Minimum Order Quantity: 1Set
Price: 14960-17000USD
Packaging Details: Wooden case
Delivery Time: 30 days after receiving your sample bottles and caps
Payment Terms: T/T
Supply Ability: 15 sets per month
Contact Now
Detailed Product Description
Name: ZCG-12L Measure Precision: ±0.5%(above 1000ml)
Material: PP, Titanium Alloy Filling Capacity: 50-2000ml
Bottle Type: Plastic Bottle,glass Bottle Application Bottle: Round Bottle,Square Bottle,Flat Bottle,etc
Control: PLC Touch Screen Control Electrical Brand: Mitsubishi,Panasonic,sick
High Light:

50ml vacuum bottle filler

,

Inline vacuum bottle filler

,

50ml Inline plastic bottle filling machine




50-2000 ML Plastic Bottle Silver Gray Inline Super Corrosive Liquid Filling Machine

Usage:

This machine is controlled by PLC program. It is an advanced filling system collecting mechanical, electrical and pneumatic system in one. The filling is realized by the way of fixed pressure, fixed flow parameter and control the time of filling. It is easy to operated and with high efficient. It can meet the international level in the 1990s. It fits all kinds of liquid filling without gas.


  • Accurate fixed position, easy operation.
  • No leaking of the filling head and accurate filling quantity.
  • Easy change the specification of the bottle and fits all the shapes of bottles.
  • Widely used and reduce the cost of processing.


Specifications:


Model ZCG-12L
Measure precision ±0.5%(above 250ml)
Material PP and Titanium alloy
Filling capacity 50-2000ml
Bottle Type Plastic Bottle,glass bottle
Application bottle Round bottle,Square bottle,Flat bottle,etc
Control PLC Touch Screen Control
Electrical Brand Mitsubishi, PANASONIC, WEINVIEW



Elements brands list:


Name Brand and materials
Servo motor Panasonic
Ballscrew WIHIN
PLC Mitsubishi
Touch screen Weinview
Air cylinder AirTAC
Electromagnetic valve SHAKO
Optoelectronic switch Sick



Applications:

1. The filling machine is made of imported non-metallic materials, suitable for corrosive liquid filling.For example,disinfectant water, clean toilet fluid and so on.

2. Fully automatic filling process.

3. It is suitable for liquid filling in chemical, pesticide and other industries.

4. The filling machine can fill more than 250ml materials, the accuracy can reach ±0.5%.



50-2000 ML Plastic Bottle Silver Gray Inline Super Corrosive Liquid Filling Machine


Competitive Advantage:


1. Control system -- Mitsubishi PLC control system, filling dosage random fine tuning.
2. Operation interface - color screen operation interface, man-machine operation interface is simple, safe and reliable.
3. Function improvement -- feeding with anti-drip device, according to the characteristics of the material can have the diving filling function.(This function is optional)
4. Electrical components -- international famous brands are adopted to ensure the safety, reliability and accuracy of the equipment;
5. Mechanical parts -- PVC and non-toxic and corrosion resistant PTFE hose are used for the parts in contact with materials.
6. Other parts of the machine are made of 304 stainless steel.
7. Function expansion - according to customer requirements for special requirements configuration, such as: material sealing, heating, sterilization, etc.
8. Counting detection -- real-time counting, intuitive reflection of work output.
9. Filling test - no filling, not enough bottles not filling.
10. Maintenance -- The machine meets GMP requirements and can be easily disassembled, cleaned and maintained.
11. Change specifications - when changing filling specifications, it is easy to make simple adjustments.
12. Environmental protection configuration -- environmental protection framework can be configured according to customer requirements, so that the operation environment of the machine is more clean and sanitary.



Company Profile:



Our company was founded in 2005, is focused on food, medicine, pesticide, chemical packaging machinery research and development, manufacturing in one of the modern science and technology enterprises, and has obtained ISO9001:2008 quality management system certification.Our products include rotary series filling machine, in-line series filling machine, environmental protection series filling machine.Automatic pressure viscous liquid filling machine.

Rotary series capping machine, linear series capping machine, self-adhesive labeling machine and so on.We will continue to provide customers with high quality equipment and perfect technical support.Warmly welcome new and old customers at home and abroad to visit and discuss cooperation.


FAQ:

Q: How many years of experience do you have in packaging machinery and equipment?
A: We have 16 years of experience in manufacturing packaging machinery and equipment.



Q: Do you guarantee the quality of your products?
A: Sure.
We take our reputation very seriously.
Quality first is our consistent principle.
The company passed the Jiangsu high-tech enterprise certification in 2020.
You can rest assured of the quality of our products.



Q: Where is your factory located?
A: Our factory is located in Jintan Economic Development Zone, Changzhou City, Jiangsu Province, China. It takes 2 hours by high-speed train to Shanghai



Q: How to install it?
A: We can provide installation.
There are two options.
The first option: we can send our engineers to your company for debugging and maintenance, and your company will bear the cost of air ticket, visa, accommodation, labor and other expenses for this trip.
Option 2: Offer an online service.



Q: how to ensure the operation of the filling machine?
A: Before delivery, we will test and debug all the machines in good condition and record the video
