Product Details:
Place of Origin: CHANGZHOU,CHINA
Brand Name: XIANFEI
Certification: ISO
Model Number: GNC-4LY
Payment & Shipping Terms:
Minimum Order Quantity: 1Set
Price: 19360-25800USD
Packaging Details: Wooden case
Delivery Time: 30 days
Payment Terms: T/T
Supply Ability: 10 sets per month
Contact Now
Detailed Product Description
Name: GNC-4LY Automatic Moving Servo Filling Machine Filling Capacity: 500-5000ml
Measure Precision: ±0.5%(above 1000ml) Electrical Brand: Mitsubishi,Panasonic,sick
Dimension(L*W*H): 2000x1300x2200 Mm Weight: 1000Kg
High Light:

GNC Control shampoo filling machine

,

500ml shampoo filling machine

,

500ml servo pump filling machine



GNC Control Shampoo Filling Machine 500ml Servo Pump Filling Machine





Brief introduction



  • This type of filling machine is a new generation of viscous liquid filling machine developed by our company according to the demand of pressure viscous liquid filling machine.
  • This machine through the piston and cylinder sliding to cooperate with the material pumping, pushing, and a servo motor control position.Open and close the solenoid valve and the air controlled filling head valve to achieve high precision and quantitative filling.
  • PLC programmable control, equipped with a 6-inch touch screen man-machine interface system, photoelectric identification movement (tracking) system in the form of modules, automatic bottle into, automatic tracking, automatic filling, automatic bottle out,



Applications:



1. GNC-4LY is our new generation of viscous liquid filling machine.Focus on filling viscous liquids.
2. It can be used for filling thick liquid such as hair shampoo.Only through simple machine adjustment can be applied to a variety of bottle shapes, such as round bottle, square bottle, flat bottle and so on
3. Many daily chemical products used in daily life can be filled.For example, hand sanitizer, body lotion, hair shampoo, laundry detergent, etc.
4. The filling liquid is pulled and pushed by the sliding of the piston and cylinder.Therefore, the filling efficiency and accuracy are greatly improved.
5. The filling machine can achieve high precision quantitative filling, can fill more than 1000ml of materials, accuracy up to ±0.5%.





Specifications:



Model GNC-4LY
Application bottle Round bottle,Square bottle,Flat bottle,etc
Measure precision ±0.5%(above 1000ml)
Filling Volume 500-5000ml
Air pressure 0. 6-0. 8Mpa
Power source 380V, 50Hz
Weight 1000Kg
Dimensions 2000x1300x2200 (mm)





Elements brands list:



Name Brand and materials
Servo motor Panasonic
Ballscrew WIHIN
Touch screen Weinview
Air cylinder AirTAC
Three-way valve XIANFEI
Electromagnetic valve SHAKO
Optoelectronic switch Sick







GNC Control Shampoo Filling Machine 500ml Servo Pump Filling Machine





Competitive Advantage:



1. The filling machine adopts the environment-friendly outer frame, which greatly improves the safety and health problems in the filling process.
2. PLC programmable control is adopted to improve the efficiency and accuracy of the filling process.
3. 6-inch touch screen man-machine interface system, simple and convenient operation.
4. Fully automated.Automatic bottling, automatic filling, more stable than the previous generation of pressure viscous liquid filling process.
5. Pneumatic components of the machine adopt Mitsubishi, Panasonic and other well-known brands, quality is guaranteed.



GNC Control Shampoo Filling Machine 500ml Servo Pump Filling Machine 0



What services can Changzhou Xianfei Packing Equipment Technology Co., Ltd. provide for you?



1. Product inspection

We have our own factory and quality control department, and we will check carefully to ensure the quality of the products before sending them to our customers



2. Sample services

We can send you a video of the machine in action.Welcome to visit our company and have a look at the machines being produced in our factory



3. Customization services

A: We can customize the machine according to the mechanical power, materials and bottles you provide

B: We can also offer you some professional advice on machinery.As you know, we have been in the machinery business for 16 years.



4. About install

We can provide installation.There are two options.

The first option: We can send our engineers to your company for debugging and maintenance, and your company will bear the cost of air ticket, visa, accommodation, labor and other expenses for this trip.

Option 2: Offer an online service.
