Product Details:
Place of Origin: Jiangsu,China
Brand Name: XIANFEI
Certification: ISO
Model Number: GNC-12L
Payment & Shipping Terms:
Minimum Order Quantity: 1Set
Price: 17600-20000USD
Packaging Details: Wooden case
Delivery Time: 30 days after receiving your sample bottles and caps
Payment Terms: T/T, L/C
Supply Ability: 15 sets per month
Contact Now
Detailed Product Description
Name: GNC-12L Automatic Pressure Viscous Liquid Filling Machine Bottle Diameter Of Suiting For: 33mm-110mm
Machinery Capacity: ≤5000bottles/hour Air Pressure: 0. 6-0. 8Mpa
Power Source: 380V, 50Hz Brand: XIANFEI
High Light:

110mm honey jar filling machine

,

380V 50Hz honey jar filling machine

,

110mm high viscosity liquid filling machine


380V 50Hz Honey Jar Filling Machine 110mm High Viscosity Liquid Filling Machine


Technical performance:

1. The machine adopts PLC programmable control and 6 Inch Touch screen man-machine interface system.
2. It implements automatic bottle entry, automatic filling, automatic bottle exit, electrical appliances and pneumatic components all adopt international brands, ensuring excellent quality and durable and stable performance.
3. The equipment is simple in structure and easy to operate.
4. It is an ideal filling equipment for high viscosity materials in China.
5. The machine is equipped with filling tightness head to prevent drip leakage and wire drawing, so as to ensure no drip leakage and wire drawing after filling.

Specifications:



Model GNC-12L
Bottle diameter of suiting for 33mm-110mm
Production capacity ≤5000bottles/hour
Air pressure 0. 6-0. 8Mpa
Power source 380V, 50Hz
Brand XIANFEI




Brief introduction:

1. The machine is equipped with a special three-way filling valve, suitable for daily chemical, food, pesticide, medicine and other industries of filling, especially for high viscosity materials (such as thick sauce, pepper sauce, tomato sauce, micro emulsion, suspension) effect is remarkable, high precision.
2. This machine adopts PCL programmable control, using 6 inch touch screen man-machine interface system, automatic bottle into, automatic filling, automatic bottle out.
3. Electrical and pneumatic components adopt international brands to ensure excellent quality and long-lasting and stable functions.


Applications:

1. GNC-12L automatic pressure viscous liquid filling machine is suitable for high viscosity material filling.
2. Excellent performance when filling daily chemical products such as laundry detergent and detergent.
3. It is also suitable for some food filling with viscosity.For example, honey, thick sauce, hot sauce, ketchup and so on.
4. Microemulsions and suspending agents needed in pesticides can also be used for filling.



380V 50Hz Honey Jar Filling Machine 110mm High Viscosity Liquid Filling Machine


Elements brands list:



Name Brand and materials
Servo motor Panasonic
Ballscrew WIHIN
PLC Mitsubishi
Touch screen Weinview
Air cylinder AirTAC
Three-way valve XIANFEI
Electromagnetic valve SHAKO
Optoelectronic switch Sick


380V 50Hz Honey Jar Filling Machine 110mm High Viscosity Liquid Filling Machine 0

Competitive Advantage:

1. This filling machine is mainly made of SUS304 or SUS316L.
2. Accurate fixed position, easy operation.
3. Adopt special three-way filling valve.
4. PLC programmable control is adopted.
5. 6-inch touch screen man-machine interface system.
6. Fully automated.Automatic bottling, automatic filling.
7. Pneumatic components adopt well-known brands, such as Mitsubishi, Panasonic, etc.
8. No leaking of the filling head and accurate filling quantity.
9. Easy change the specification of the bottle and fits all the shapes of bottles.


Company Profile:

Our company was founded in 2005, is focused on food, medicine, pesticide, chemical packaging machinery research and development, manufacturing in one of the modern science and technology enterprises, and has obtained ISO9001:2008 quality management system certification.Our products include rotary series filling machine, in-line series filling machine, environmental protection series filling machine.Automatic pressure viscous liquid filling machine.
Rotary series capping machine, linear series capping machine, self-adhesive labeling machine and so on.We will continue to provide customers with high quality equipment and perfect technical support.Warmly welcome new and old customers at home and abroad to visit and discuss cooperation.


FAQ:
Q: How many years of experience do you have in packaging machinery and equipment?
A: We have 16 years of experience in manufacturing packaging machinery and equipment.

Q: Do you guarantee the quality of your products?
A: Sure.We take our reputation very seriously.Quality first is our consistent principle.The company passed the Jiangsu high-tech enterprise certification in 2020.You can rest assured of the quality of our products.

Q: Where is your factory located?
A: Our factory is located in Jintan Economic Development Zone, Changzhou City, Jiangsu Province, China. It takes 2 hours by high-speed train to Shanghai

Q: How to install it?
A: We can provide installation.There are two options.The first option: we can send our engineers to your company for debugging and maintenance, and your company will bear the cost of air ticket, visa, accommodation, labor and other expenses for this trip.Option 2: Offer an online service.

Q: How to ensure the operation of the filling machine?
A: Before delivery, we will test and debug all the machines in good condition and record the video for your inspection.
