275ml Carbonated Beverage Filling Machine

China 275ml Carbonated Beverage Filling Machine supplier

Large Image :  275ml Carbonated Beverage Filling Machine

Product Details:

Place of Origin: CHINA MAINLAND
Brand Name: EQS
Certification: CE/ISO
Model Number: DCGF32-32-10

Payment & Shipping Terms:

Minimum Order Quantity: 1 set
Price: USD
Packaging Details: Wooden case packing plus film
Delivery Time: 45 DAYS
Supply Ability: 10SETS PER MONTH
Detailed Product Description
Filling Type: Isobaric Filling Machine Structure: Washer ,Filler,Caper 3in1 Macine
Voltage: Customised Condition: New
Bottle Type: Glass Bottle Service: Engineer Will Be Customer Place
Garrantee: 12 Months

275ml Glass Bottle Carbonated Beverage Filling Machine





Product description

  •  request capacity:9000bottles per hours (stardand for 500ml bottle)
  •  filling content : 330-2000ml
  •  filling products :Carbonated beverage
  •  Filling temperature: low temperature
  •  .washing fashion: automatic washing (sterile water spray)
  •  bottle type :Glass bottle
  •  bottle diameter ,height: by buyer
  •  capper type: Gland
  •  power:380V,50HZ
  •  the flow of the production :source water →water treatment plant →filling equipment→packing
  •  equipment→products

275ml Carbonated Beverage Filling Machine

Characteristic

1.The most advanced technology from Japan and Germany is employed in the design.The gravity fixed liquid surface filling is used.The filling is fast,the amount of liquid is accurately controlled and the dropping and leakage are avoided.

2.The magnetic torque is used for screw capping.The power of screw capping can be adjusted without steps.The power of the screw capping can also be fixed,and the caps will not be damaged,the capping is reliable.

3.Horizon swirl air power caps sorting device is used to ayoid damaging the surface of caps, and when there is a shortage of caps in the caps storage tank,an alarm signal will be generated and the caps will be fed automatically.

4.The whole machine is controlled by PLC .The amount of the drinks in the storage tank can be controlled automatically.The filling and capping will be stopped automatically when there is no bottle. When bottles are crapmed wrongly or when caps are not available, the machine can be stopped automatically.

5.The frequency changing technology is used to adjust the operation speed steplessly.The production capacity can be displayed digitally and can be adjusted conveniently.

6.The frame is made of high quality stainless steel,covered by S.S.304,the filling valve parts direct contact with water are made in SS316 stainless steel .The critical electronic components are from Mitsubishi,Omron,etc.,the pneumatic devices are also from international famous brand.

7. all product contact parts will be constructed of type 316 stainless steel.the bottle is feeding by wind

blowing system, the caps is feeding by a full-automatic feeding system, smoothly and high efficiency.

8. The carbonated beverage filler have "double pre-evacuation capabilities".the first evaculation is removing all air from the bottles by vacuum, the second evacuation is injecting nitrogen or CO2 in bottles then removing it. After filling carbonated juice.

9. When filling, no bottles, broken bottles are not filling.

10. .Spring cramps are used in the bottle washing proces.The empty bottles can be turned over 180* along the conveying rail.There are two times of internal and external washing,the efficiency of bottle washing is high.



Main parameter

Filling head : 32 washing head : 32 capping : 10

Capacity :9000B/H for 500ml

Suitable of bottle: highness:160~320mm

Diameter: Φ50~Φ95mm

Suitable of cap: plastic screw cap

Filling temperature : 2℃ ~ 8℃

CO2 wastage :150g/hl

Filling type : equipoise press

Filling pressure : 0.25-0.4 Mpa

Main power : 6KW

Air compress : 0.4 m3/h

Use washing water:1 m3/h

Prower: 380V ,50HZ

Dimension : L3600*W2650*H2350mm

Weight : 5500kg



Pictures:



1, washer

275ml Carbonated Beverage Filling Machine

2, filler

275ml Carbonated Beverage Filling Machine

3,caper

275ml Carbonated Beverage Filling Machine
