750ml Glass Bottle Cocktail Wine Filling machine with Gas Bottling machine 8000BPH DCGF18-18-6

750ml Glass Bottle Cocktail Wine Filling machine with Gas Bottling machine 8000BPH DCGF18-18-6

    • 750ml Glass Bottle Cocktail Wine Filling machine with Gas Bottling machine 8000BPH DCGF18-18-6
    • 750ml Glass Bottle Cocktail Wine Filling machine with Gas Bottling machine 8000BPH DCGF18-18-6
  • 750ml Glass Bottle Cocktail Wine Filling machine with Gas Bottling machine 8000BPH DCGF18-18-6

    Product Details:

    Place of Origin: CHINA MAINLAND
    Brand Name: EQS
    Certification: CE/ISO
    Model Number: DCGF18-18-6

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 set
    Price: USD
    Packaging Details: wooden case packing plus wrapping film
    Delivery Time: 45 days later after deposit
    Payment Terms: L/C, T/T
    Supply Ability: 10PCS PER MONTH
    Detailed Product Description
    Type: Filling Machine Condition: New
    Application: Carbonated Liquids/ Water Automatic Grade: Fully Automatic
    Filling Tolerance: +-2% Voltage: Customised
    Filling Type: Washer,Filler And Capper 3in1 Filling Machine After Sales Service: Engineer Will Be Aveilabel To Customer Place

    750ml Glass Bottle Cocktail Wine Filling machine with Gas Bottling machine 8000BPH DCGF18-18-6



    1. General description:



    The series equipment is used in producing all kinds of soda drink contained with polyester with bottle.Washing ,filling,sealing

    can carried out on the same machine.The design of the machine is scientific and reasonable.



    2. Deatails of each equipment:



    Rinser

    750ml Glass Bottle Cocktail Wine Filling machine with Gas Bottling machine 8000BPH DCGF18-18-6

    1. The rotary wheel is a fully stainless steel welded structure.

    2. The machine applies unique overturning bottle clamp, which is an innovation of our company. This

    bottle clamp grips

    bottle at neck position, avoiding bottle mouth thread contamination caused by rubber gripper block of a

    traditional bottle

    clamp. Made of SUS304 stainless steel, this bottle clamp is hygienic and durable.

    3. The high efficiency atomizing spay nozzle installed on bottle clamp is capable of cleaning any part of

    bottle inner wall,

    and also saves rinsing water.

    4. All sliding bushes of lifting device use Igus (Germany) anti-corrosion maintenance free bearing.

    5. The rinser is driven by driving system positioned inside machine frame via gear transmission.

    6. Transfer starwheel

    7. Made of stainless steel of superior quality.



    Filler

    750ml Glass Bottle Cocktail Wine Filling machine with Gas Bottling machine 8000BPH DCGF18-18-6

    l. Rotary wheel fully made of stainless steel SUS 304.

    2. Gravity filling method.

    3. Filling valves are made of SUS316L.

    4. Filling valves are reasonably structured with accurate filling.

    5. Bottles go up and down in the function of cam through elevator, to process filling with contact to bottle-mouth.

    6. Level of cylinder is controlled with float-ball.

    7. Filler is driven through gears inside the machine frame.

    8. Link-wheels in rinser, filler and capper are transported in ringed support of bottle-neck.



    Capper

    750ml Glass Bottle Cocktail Wine Filling machine with Gas Bottling machine 8000BPH DCGF18-18-6

    Capper is the machine with highest precision, influence very much with the stability and reliability of the filling monoblock.

    Our capper features as follows:

    l.The equipment is designed with the support of experts from school of engineering and mechanical in Shanghai Jiao

    Tong University, and uses the technology of Arol from Italy, most advance technology in the world, developed with the

    experience of asepsis filling machine. For example,

    1) extruding wheel (main part to control the stability when sealing), uses the technology of Arol. Kinematical and kinetic

    design of the wheel by experts improves the stability and credibility of the equipment.

    2) Sealing faucet (main part to control the credibility of sealing), is improved by experts with the design of alnico. Besides

    the magnetic contortion variation device, there is variation dial which makes variation more easily. The benefit of this design

    is not only it can set the contortion, but also it makes contortion more precise and credible, and reduces inferior.



    3. Technical parameter:



    Model DCGF16/12/6 DCGF18/18/6 DCGF24/24/8 DCGF32/32/12 DCGF40/40/12 DCGF50/50/15
    Washing head 16 18 24 32 40 48
    Filling head 12 18 24 32 40 48
    Capping head 6 6 8 12 12 12

    Production Capacity:

    500ml(bph)

    4000 6000 10000 14000 17000 24000
    Suitable Bottle height(mm) 150-340
    Suitable Bottle diameter(mm) 60-95
    Suitable cap diameter (mm) 50-110
    Installed capacity(KW) 3.13 3.84 3.84 5.6 6.3 7.3
    Overall Size L×W×H(mm) 2400×1670×2350 2470×1970×2350 2865×2170×2350 3700×2570×2350 3800×2950×2400 4500×3400×2400
    Total Weight:(kg) 2500 3000 4000 5000 6000 7000



    4. Company Introduction:



    Zhangjiagang EQS Machinery Co., Ltd is a professional manufacturer for Beer and Beverage Filling Machine. We're located in Zhangjiagang, north part of Suzhou, about 130 kilometers away from Shanghai.

    With more than 10 years' experiences in R&D, we are able to design products for individual customer's request. As an ISO9001:2000 company, we have a set of quality control processes. It ensures we can deliver high standard qualified products to our customers. Moreover, our products have passed European CE Certification.

    750ml Glass Bottle Cocktail Wine Filling machine with Gas Bottling machine 8000BPH DCGF18-18-6
